4-4 Range, Digits, Rate, Bandwidth, and Filter Model 2700 Multimeter/Switch System User’s Manual
Remote programming — range
Range commands
The commands to set range are listed in Table 4-2. Additional information on these
commands follow the table.
NOTE Query commands and some optional command words are not included in
Table 4-2. All commands for the SENSe subsystem are provided in Table 15-5.
Table 4-2
Range commands
Commands
1, 2
Description Default
[SENSe[1]] Optional root command.
:VOLTage[:DC]:RANGe <n> [, <clist>] Select DCV range; <n> = 0 to 1010 (V). 1000
:VOLTage[:DC]:RANGe:AUTO <b>
[, <clist>]
Control DCV auto range; <b> = ON or OFF. ON
:VOLTage:AC:RANGe <n> [, <clist>] Select ACV range; <n> = 0 to 757.5 (V). 750
:VOLTage:AC:RANGe:AUTO <b> [, <clist>] Control ACV auto range; <b> = ON or OFF. ON
:CURRent[:DC]:RANGe <n> [, <clist>] Select DCI range; <n> = 0 to 3 (A). 3
:CURRent[:DC]:RANGe:AUTO <b>
[, <clist>]
Control DCI auto range; <b> = ON or OFF. ON
:CURRent:AC:RANGe <n> [, <clist>] Select ACI range; <n> = 0 to 3 (A). 3
:CURRent:AC:RANGe:AUTO <b>
[, <clist>]
Control ACI auto range; <b> = ON or OFF. ON
:RESistance:RANGe <n> [, <clist>] Select Ω2 range; <n> = 0 to 120e6 (Ω). 120e6
:RESistance:RANGe:AUTO <b> [, <clist>] Control Ω2 auto range; <b> = ON or OFF. ON
:FRESistance:RANGe <n> [, <clist>] Select Ω4 range; <n> = 0 to 120e6 (Ω). 120e6
:FRESistance:RANGe:AUTO <b> [, <clist>] Control Ω4 auto range; <b> = ON or OFF. ON
Channel list parameter:
<clist> = (@SCH)
where: S = Mainframe slot number (1 or 2)
CH = Switching module channel number (must be 2 digits)
Examples: (@101) = Slot 1, Channel 1
(@101, 203) = Slot 1, Channel 1 and Slot 2, Channel 3
(@101:110) = Slot 1, Channels 1 through 10
1. The <clist> parameter is used to configure one or more channels for a scan. Each channel in the <clist> must be set to the function
specified by the range command. If not, a conflict error (-221) will occur. For example, VOLTage:AC:RANGe 1, (@101) is only
valid if scan channel 101 is set for the ACV function.
2. [:DC] is optional for the commands to set DCV and DCI range.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
