8-18 Triggering Model 2700 Multimeter/Switch System User’s Manual
Output Trigger — The Model 2700 will send one or more output triggers. The output
trigger is applied to the Trigger Link connector on the rear panel. It can be used to trigger
an external instrument to perform an operation.
The trigger model can be configured to output a trigger after the completion of a series of
measurements, or after every measurement. For example, with the sample counter set to
10 and the trigger counter set to one, a trigger will be sent after the 10 measurements are
performed. If instead, the trigger counter is set to 10 and the sample counter is set to 1, a
trigger will be sent after each measurement.
Triggering commands
Commands for triggering are summarized in Table 8-2.
Table 8-2
SCPI commands — triggering
Commands Description Default Ref
ABORt Reset trigger system. a
INITiate[:IMMediate] Initiate one trigger cycle. b
INITiate:CONTinuous <b> Enable/disable continuous initiation; ON or OFF. Note 1 c
FETCh? Request the last reading(s). d
READ? Perform an ABORt, INITiate, and a FETCh? d
TRIGger:SOURce <name> Select control source; IMMediate, TIMer, MANual,
BUS, or EXTernal.
IMM e
TRIGger:TIMer <n> Set timer interval; 0 to 999999.999 (sec). 0.1
TRIGger:COUNt <NRf> Set trigger count; 1 to 55000 or INFinity. Note 2
TRIGger:DELay <n> Set delay; 0 to 999999.999 (sec). 0
TRIGger:DELay:AUTO <b> Enable or disable auto delay. f
TRIGger:SIGNal Loop around control source. g
SAMPle :COUNt <NRf> Set sample count; 1 to 55000. 1 h
[:SENSe[1] Optional root command for HOLD commands.
i
:HOLD:WINDow <NRf> Set Hold window in %; <NRf> = 0.01 to 20. 1
:HOLD:COUNt <NRf> Set Hold count; <NRf> = 2 to 100. 5
:HOLD:STATe <b> Enable or disable Hold. OFF
:SYSTem:BEEPer:STATe <b> Enable or disable the beeper. ON
*RST Restore *RST defaults (see “Default” column of this
table). Places 2700 in the idle state.
Notes:
1. SYSTem:PRESet enables continuous initiation.*RST disables continuous initiation.
2. SYSTem:PRESet sets the trigger count to INF (infinity). *RST sets the count to 1.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
