14-2 FORMat and Misc SYSTem Commands Model 2700 Multimeter/Switch System User’s Manual
FORMat commands
The commands in this subsystem are used to select the format for transferring data,
Table 14-1, over the bus.
FORMat[:DATA] <type>[,<length>]
Parameters ASCii = ASCII format
SREal = Binary IEEE-754 single precision format
REAL, 32 = Binary IEEE-754 single precision format
DREal = Binary IEEE-754 double precision format
REAL, 64 = Binary IEEE-754 double precision format
NOTE <length> is not used for the ASCii, SREal, or DREal parameters.
The response to READ?, FETCh?, MEASure?, TRACe:DATA?, CALC1:DATA?, or
CALC2:DATA? over the GPIB can be returned in either the ASCii or binary format. All
other queries are returned in ASCii, regardless of the selected format. Over the RS-232
interface, only the ASCII format is allowed.
NOTE Regardless of which data format for output strings is selected, the instrument
will only respond to input commands using the ASCII format.
Table 14-1
SCPI commands — data format
Command Description Default
FORMat[:DATA] <type>[,<length>] Specify data format; ASCii, SREal, REAL, 32,
DREal, or REAL, 64.
ASCii
FORMat:ELEMents <item list> Specify data elements; READing, UNITs, TSTamp,
RNUMber, CHANnel, or LIMits.
All 3
FORMat:BORDer <name> Specify byte order; NORMal or SWAPped. (see Note)
Note: *RST default is NORMal. SYSTem:PRESet default is SWAPped.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
