Model 2700 Multimeter/Switch System User’s Manual Getting Started 1-25
Remote programming — default and user setups
Default and user setup commands are listed in Table 1-5.
NOTE The SYSTem:PRESet and *RST defaults are listed in the SCPI tables in
Section 15.
Programming example
*SAV 2 ' Save present setup in memory location 2.
SYST:POS SAV2 ' Specify SAV2 setup as the power-on setup.
*RST ' Return 2700 to RST defaults.
*RCL 2 ' Return 2700 to setup stored in memory location 2.
Setting Factory *RST Set Diff
Voltage (AC and DC)
dB Off Off
Reference 1.0 1.0
Digits (AC) 5H digits 5H digits
Digits (DC) 6H digits 6H digits
Filter On Off ✓
Window 0.1% 0.1%
Count 10 10
Type Moving Repeat ✓
Range Auto Auto
Rate (DC) Slow (5 PLC) Slow (5 PLC)
Rel Off Off
Note: With a Model 7700, 7706, or 7708 installed, the default sensor junction is Internal. Otherwise, the Simulated (23ºC) junction is
selected.
Table 1-5
Default setup commands
Commands Description
SYSTem:PRESet Restore SYSTem:PRESet defaults.
*RST Restore *RST defaults.
*SAV <NRf> Save settings as user setup; <NRf> = 0, 1, 2, or 3.
*RCL <NRf> Restore user saved setup; <NRf> = 0, 1, 2, or 3.
SYSTem:POSetup <name> Specify power-on setup; <name> = RST, PRESet, SAV0,
SAV1, SAV2, or SAV3.
Table 1-4 (continued)
Default settings

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
