Keithley 2700 User Manual

1-24 Getting Started Model 2700 Multimeter/Switch System User’s Manual
Setting Factory *RST Set Diff
RS-232 Off Off
Baud rate No effect No effect
Flow control XonXoFF XonXoFF
Terminator No effect No effect
Scanning Disabled Disabled
Auto scan No (off) No effect ✓
Type (Simple or Advanced) No effect No effect
Simple scan
Minimum channel 101, 201, 301, 401, or 501 101, 201, 301, 401, or 501
Maximum channel No effect No effect
Timer Off Off
Reading count No effect No effect
Advanced scan
Setup No effect No effect
Immediate trigger On On
Limit triggers Off Off
Timer Off Off
Reading count No effect No effect
Temperature
Digits 5H digits 5H digits
Filter On Off ✓
Window 0.1% 0.1%
Count 10 10
Type Moving Repeat ✓
Rate Slow (5 PLC) Slow (5 PLC)
Rel Off Off
Sensor Thermocouple Thermocouple
Junction See Note See Note
Open detector No (off) No (off)
Type K K
Units °C °C
Timestamp No effect No effect
Triggering Continuous One-shot ✓
Delay Auto Auto
Source Immediate Immediate
Reading hold Off Off
Window 1% 1%
Count 5 5
Table 1-4 (continued)
Default settings

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
