Model 2700 Multimeter/Switch System User’s Manual Getting Started 1-23
Setting Factory *RST Set Diff
Limits Off Off
LO Limit 1 -1 -1
HI Limit 1 +1 +1
LO Limit 2 -2 -2
HI Limit 2 +2 +2
Line Synchronization Off Off
Math
mX+B Off Off
Scale Factor 1.0 1.0
Offset 0.0 0.0
Units “X” “X”
Percent Off Off
Reference 1.0 1.0
1/X (Reciprocal) Off Off
Monitor Off Off
Output
Beeper Never Never
Digital Output Off Off
Logic Sense High High
Pulse No (off) No (off)
Ratio Off Off
Resistance (Ω2 and Ω4)
Digits 6H digits 6H digits
Filter On Off ✓
Window 0.1% 0.1%
Count 10 10
Type Moving Repeat ✓
Offset compensation (OCOMP) Off Off
Range Auto Auto
Rate Slow (5 PLC) Slow (5 PLC)
Rel Off Off
Table 1-4 (continued)
Default settings

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
