1-22 Getting Started Model 2700 Multimeter/Switch System User’s Manual
Table 1-4
Default settings
Setting Factory *RST Set Diff
Auto channel configuration No (off) No effect ✓
Autozero On On
Buffer No effect No effect
Auto clear Yes (on) No effect ✓
Channel Average Off Off
Closed channels None None
Closure count interval No effect No effect
Continuity
Beeper On On
Digits 4H digits 4H digits
Range 1kΩ 1kΩ
Rate Fast (0.01 PLC) Fast (0.01 PLC)
Threshold level 10Ω 10Ω
Current (AC and DC)
Bandwidth (AC) 30 30
Digits (AC) 5H digits 5H digits
Digits (DC) 6H digits 6H digits
Filter On Off ✓
Window 0.1% 0.1%
Count 10 10
Type Moving Repeat ✓
Range Auto Auto
Rate (DC) Slow (5 PLC) Slow (5 PLC)
Rel Off Off
Frequency and Period
Digits 6H digits 6H digits
Range 10V 10V
Rate (aperture) 1 second 1 second
Rel Off Off
Function DCV
GPIB No effect No effect
Address No effect (16 at factory) No effect (16 at factory)
Keyclick On On

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
