Model 2700 Multimeter/Switch System User’s Manual Range, Digits, Rate, Bandwidth, and Filter 4-11
Table 4-5
Rate and bandwidth commands
Commands
1, 7
Description Default
Integration rate commands
[SENSe[1]] Optional root command.
:VOLTage[:DC]:NPLCycles <n> [, <clist>] Set rate for DCV in PLCs; <n> = 0.01 to x
2
. 5.0
:VOLTage[:DC]:APERture <n> [, <clist>] Set rate for DCV in secs; <n> = x to 1
3
. (Note 4)
:VOLTage:AC:NPLCycles <n> [, <clist>] Set rate for ACV in PLCs; <n> = 0.01 to xx
2,5
. 5.0
:VOLTage:AC:APERture <n> [, <clist>] Set rate for ACV in secs; <n> = x to 1
3,5
. (Note 4)
:CURRent[:DC]:NPLCycles <n> [, <clist>] Set rate for DCI in PLCs; <n> = 0.01 to x
2
. 5.0
:CURRent[:DC]:APERture <n> [, <clist>] Set rate for DCI in secs; <n> = x to 1
3
. (Note 4)
:CURRent:AC:NPLCycles <n> [, <clist>] Set rate for ACI in PLCs; <n> = 0.01 to x
2,5
. 5.0
:CURRent:AC:APERture <n> [, <clist>] Set rate for ACI in secs; <n> = x to 1
3,5
. (Note 4)
:RESistance:NPLCycles <n> [, <clist>] Set rate for Ω2 in PLCs; <n> = 0.01 to x
2
. 5.0
:RESistance:APERture <n> [, <clist>] Set rate for Ω2 in secs; <n> = x to 1
3
. (Note 4)
:FRESistance:NPLCycles <n> [, <clist>] Set rate for Ω4 in PLCs; <n> = 0.01 to x
2
. 5.0
:FRESistance:APERture <n> [, <clist>] Set rate for Ω4 in secs; <n> = x to 1
3
. (Note 4)
:TEMPerature:NPLCycles <n> [, <clist>] Set rate for TEMP in PLCs; <n> = 0.01 to x
2
. 5.0
:TEMPerature:APERture <n> [, <clist>] Set rate for TEMP in secs; <n> = x to 1
3
. (Note 4)
Bandwidth commands
[SENSe[1]] Optional root command.
:VOLTage:AC:DETector:BANDwidth
<NRf> [, <clist>]
Set AC bandwidth for ACV in Hertz; <NRf> =
3 to 3e5
6
.
30
:CURRent:AC:DETector:BANDwidth
<NRf> [, <clist>]
Set AC bandwidth for ACI in Hertz;
<NRf> = 3 to 3e5
6
.
30
Channel list parameter:
<clist> = (@SCH)
where: S = Mainframe slot number (1 or 2)
CH = Switching module channel number (must be 2 digits)
Examples: (@101) = Slot 1, Channel 1
(@101, 203) = Slot 1, Channel 1 and Slot 2, Channel 3
(@101:110) = Slot 1, Channels 1 through 10
Notes:
1. The <clist> parameter is used to configure one or more channels for a scan. Each channel in the <clist> must be set to the function
specified by the command. If not, a conflict error (-221) will occur. For example, RESistance:NPLCycles 1, (@101) is only valid if
scan channel 101 is set for the
Ω2 function.
2. For 60Hz line power, x = 60. For 50Hz line power, x = 50.
3. For 60Hz line power, x = 1.67e-4. For 50Hz line power, x = 2e-4.
4. For 60Hz line power, the default is 16.67msec. For 50Hz line power, the default is 20msec.
5. Commands to set rate for ACV and ACI are only valid if bandwidth is set to 300 (300Hz to 300kHz). See “Rate and bandwidth
conflict error,” page 4-12, for details.
6. The instrument will actually accept a parameter value up to 10e6, but it will default to 3e5.
7. [:DC] is optional for the commands to set DCV and DCI integration rate.

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
