Keithley 2700 User Manual

Model 2700 Multimeter/Switch System User’s Manual Buffer 6-7
Figure 6-1
Recalling buffer data — relative timestamp
Figure 6-2
Recalling buffer data — real-time clock timestamp
RDG NO. 10 Reading Value Absolute Timestamp Delta Timestamp
RDG NO. 9 Reading Value Absolute Timestamp Delta Timestamp
RDG NO. 8 Reading Value Absolute Timestamp Delta Timestamp
RDG NO. 7 Reading Value Absolute Timestamp Delta Timestamp
RDG NO. 6 Reading Value Absolute Timestamp Delta Timestamp
RDG NO. 5 Reading Value Absolute Timestamp Delta Timestamp
RDG NO. 4 Reading Value Absolute Timestamp Delta Timestamp
RDG NO. 3 Reading Value Absolute Timestamp Delta Timestamp
RDG NO. 2 Reading Value Absolute Timestamp Delta Timestamp
RDG NO. 1 Reading Value Absolute Timestamp Delta Timestamp
STD DEV Standard Deviation Value No Timestamp
Average Average Value No Timestamp
Peak-to-Peak Peak-to-Peak Value No Timestamp
Min At XX Minimum Value Absolute Timestamp Delta Timestamp
Max At XX Maximum Value Absolute Timestamp Delta Timestamp
RANGE
RANGE
RDG NO. 10 Reading Value Time Date
RDG NO. 9 Reading Value Time Date
RDG NO. 8 Reading Value Time Date
RDG NO. 7 Reading Value Time Date
RDG NO. 6 Reading Value Time Date
RDG NO. 5 Reading Value Time Date
RDG NO. 4 Reading Value Time Date
RDG NO. 3 Reading Value Time Date
RDG NO. 2 Reading Value Time Date
RDG NO. 1 Reading Value Time Date
STD DEV Standard Deviation Value No Time No Date
Average Average Value No Time No Date
Peak-to-Peak Peak-to-Peak Value No Time No Date
Min At XX Minimum Value Time Date
Max At XX Maximum Value Time Date
RANGE
RANGE

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
