Model 2700 Multimeter/Switch System User’s Manual KE2700 Instrument Driver Examples H-7
Name Manual Reference Brief Description
MultiRange Page 4-5 (Ex. 1 & 2) Demonstrates various range and function settings.
Ohmm Page 3-55 (Ex. 2) Demonstrates measuring offset compensated ohms in one-shot
trigger mode.
Percent Page 5-15 (Ex. 2) Demonstrates percent calculation.
PollSQR Page 11-9 (Prog Ex.) Demonstrates serial poll operation and use of SRQs.
Prmr Page 11-20 (Prog Ex.) Demonstrates reading the measurement condition and event
registers.
RAFilter Page 4-22 (Ex. 2) Demonstrates use of repeating filter.
RateBandwidth Page 4-13 (Ex. 1 & 2) Demonstrates rate and bandwidth settings.
Ratio1 Page 5-20 (Ex. 1) Demonstrates ratio calculation.
Ratio2 Page 5-20 (Ex. 2) Demonstrates ratio and channel average functions.
ReadError-
Queue
Page 11-23 (Prog Ex.) Demonstrates reading the error queue.
Relative1 Page 5-7 (Ex. 1) Demonstrates acquiring and using a relative reference reading.
Relative2 Page 5-7 (Ex. 2) Demonstrates setting a relative reference value.
Relative3 Page 5-7 (Ex. 3) Demonstrates zero correction using relative value.
ScanChan Page 7-32 (Prog Ex.) Demonstrates scanning 10 channels.
Simple1 None Use Case 1 — 30-channel scan using 7708 module:
• 30 channels DCV (10V range).
• 10 channels type T thermocouple temperature.
• Measurement speed (rate) – 1 plc.
• Filter – Disabled (no filtering).
• Buffer – Store 120 reading strings. Buffer elements include
reading only.
• Triggering – Bus control source.
Table H-1 (continued)
Visual Basic and CVI (C) examples
