Keithley 2700 User Manual

H-18 KE2700 Instrument Driver Examples Model 2700 Multimeter/Switch System User’s Manual
Name
Manual
Reference Brief Description
Simple5 None Use Case 5 — 32-channel scan using 7701 module.
• Common-side 4-wire ohms measurements (CSIDe mode).
• Dry-circuit ohms option for Model 2750.
• Install jumpers to connect Input Hi and Sense Hi directly to
DUT (common-side bus).
• Install jumpers to connect channel 35 to Sense Lo and Input Lo.
• Buffer – Store 32 reading strings. Buffer elements include
reading only.
• Triggering – Immediate control source.
Simple6 None Use Case 6 — Scan 160 channels using 7703 module (see
NOTE):
• Type K thermocouple (TC) temperature measurements.
• Reference junction – Simulated.
• Measurement speed (rate) – 0.01 plc.
• Filter – Disabled (no filtering).
• Buffer – Store 160 reading strings. Buffer elements include
reading only.
• Triggering – Bus control source.
NOTE: When using a module that has a built-in cold junction,
use the Internal reference junction. Keep in mind that the
buffer will have to be modified to accommodate the
number of scanned channels. Modules that have cold
junction include:
7700 and 7706 modules – 20 available TC channels
7708 module – 40 available TC channels
Table H-2 (continued)
LabVIEW examples

Keithley 2700 Specifications

General

Type	Digital Multimeter
Measurement Functions	DC Voltage, AC Voltage, DC Current, AC Current, Resistance, Frequency, Temperature
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Temperature Range	-200°C to +1372°C
Display	Vacuum Fluorescent Display
Connectivity	IEEE-488, RS-232
Channels	10
Power Supply	100V to 240V AC, 45Hz to 66Hz
DC Current Range	10 µA to 3 A
AC Current Range	10 µA to 3 A
Temperature Measurement	Thermocouple, RTD
