Keysight Technologies B1505A

5-6 Keysight B1505A Configuration and Connection Guide
Connection Guide for Wafer Prober and Your Own Test Fixture
Connection Overview
Also see the following tables.
• Table 5-2, "To Configure HVMCU by Using N1266A."
• Table 5-3, "To Connect N1258A Module Selector."
• Table 5-4, "To Connect N1267A Fast Switch."
• Table 5-5, "To Make UHC Measurement Path."
• Table 5-6, "To Make UHV Measurement Path."
Table 5-2 To Configure HVMCU by Using N1266A
B1505A terminals Required cables N1266A terminals
MCSMU
1
1. HCSMU is substitutable. Then use 16493S HCSMU cable, N1254A-103 adapter for Force, and
N1254A-517 adapter for Sense.
Force 16494A-001 Triaxial cable, 1.5 m, 1 ea.
I Control
Force
Sense 16494A-001 Triaxial cable, 1.5 m, 1 ea. Sense
MCSMU
1
Force 16494A-001 Triaxial cable, 1.5 m, 1 ea.
V Control
Force
Sense 16494A-001 Triaxial cable, 1.5 m, 1 ea. Sense
HVSMU
Force 16493T-001 HVSMU cable, 1.5 m, 1 ea. HVSMU
GNDU
16493L-001 GNDU cable, 1.5 m, 1 ea.
GNDU
Digital I/O 16493G-001 Digital I/O connection cable, 1.5 m, 1 ea. Digital I/O Input
N1266A terminals Required accessories and cables
Connection inside of
the shielding box
Output High 16493T HVSMU cable, 3 m or 1.5 m, 1 ea.
N1254A-501 HV(jack)-HV(jack) adapter, 1 ea.
N1262A-001/002 R-box and 16493T cable, optional
HV(plug) cable, 1 ea.
or SHV(plug) cable, 1 ea.
for N1262A-001/002
Low N1261A-002/004 GNDU protection adapter, 1 ea.
16493L GNDU cable, 3 m or 1.5 m, 1 ea.
BNC(m) cable, 2 ea. for
N1261A-002 or
SHV(plug) cable, 2 ea. for
N1261A-004
LINE Power cable, 1 ea., for connecting to power line 
