118 Keysight N9010A EXA Service Guide
Instrument Messages
Condition Errors 1 to 99, Calibration
Condition Errors 65 to 92, Calibration Needed (Extended)
Errors with instrument internal alignment routines.
An event with the error number shown in the table means the condition has
been detected.
When the condition is cleared, an event with the error number plus 1000 is
generated.
For example, error 66 indicates that the requirement for an Alignment of the
EMI conducted frequency range has been detected; error 1066 indicates that
failure has been cleared.
An E in the Error or Warning column means that an error is put up on the front
panel and sent out to SCPI when this condition is detected. A W in this column
means that a Warning is put up on the front panel but nothing goes out to
SCPI. Nothing in this column means nothing is put up; status bit only.
Err# Message Error or
Warning
Verbose/Correction Information
65 unused bit0 is set
66 Align 9kHz-30MHz required E An EMI conducted frequency range alignment is
needed.
68 Align 30MHz-1GHz required E An EMI radiated frequency range alignment is
needed.
72 Input Attenuation not
calibrated
E Corrected measurements have been requested
and the required RF front-end setting of x dB
has not been calibrated.
74 unused bit5 is set
76 unused bit6 is set
78 unused bit7 is set
80 unused bit8 is set
82 unused bit9 is set
84 unused bit10 is set
86 unused bit11 is set
88 unused bit12 is set
90 unused bit13 is set
92 unused bit14 is set
