Keysight N9010A EXA Service Guide 135
Instrument Messages
Condition Errors 601 to 699, Error Summaries
Condition Errors 601 to 699, Error Summaries
The instrument hardware status registers keep track of various error
conditions. The bits in this register summarize the status of several different
status registers.
An event with the error number shown in the table means the condition has
been detected.
When the condition is cleared, an event with the error number plus 1000 is
generated.
For example, error 601 indicates a bit in the Voltage Summary register has
been set, error 1601 indicates that failure has been cleared.
An E in the Error or Warning column means that an error is put up on the front
panel and sent out to SCPI when this condition is detected. A W in this column
means that a Warning is put up on the front panel but nothing goes out to
SCPI. Nothing in this column means nothing is put up; status bit only.
Err# Message Error or
Warning
Verbose/Correction Information
601 Voltage
603 Current
605 Time
607 Power
609 Temperature
611 Frequency
613 Phase
615 Modulation
617 Calibration
619 Integrity
621 unused bit10 is set
623 CALL
625 unused bit12 is set
627 Integrity
629 Command Warning
