398 Keysight N9010A EXA Service Guide
Replaceable Parts
Replaceable Parts
Replaceable Parts
Some of the assemblies listed in the following table are related to options that
are available with the EXA Signal Analyzer. These options are described below.
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
A1A1
Front Frame Assembly Replacement Kit
a
N9020-60110
A1A1MP1 Front Frame
W1312-20108
b
A1A1MP2
Main Keypad Overlay
b
Option 503, 507, 513, 526 N9030-80002
Option 532, 544 N9030-80011
A1A1MP3 Connector Overlay E4410-80109
A1A1MP4 Front Frame Ground Spring W1312-00021
A1A1MP5 Braided Gasket -----
A1A1MP6 Chromeric Gasket -----
A1A1MP7 Front Frame Top Trim Strip (Use with Option PRC, Portable) W1312-40004
A1A1MP8 Front Frame Top Trim Strip
(Use with standard Bench analyzer)
W1312-40019
A1A1MP9-10 Front Frame Side Trim Strip W1312-40005
A1A1MP11-12 Vinyl Side Trim (Use with standard Bench Analyzer) 5041-9172
A1A1MP13-17 Hole Plug 6960-0525
A1A1MP18 Cover Plate N9020-00002
A1A1MP19 Overlay, Left Display N9020-80026
A1A1MP20-21 Hole Plug, for 0.25 inch hole 6960-0076
A1A2 Front Panel Interface Board
Serial number ≥ MY/SG51250000 N9020-60277
Serial number ≥ MY/SG48010101, US48010001 to
Serial number < MY/SG51250000
W1312-60042
Serial number < MY/SG48010101
c
N9020-60033
A1A2MP1 Speaker 9164-0453
A1A2MP2 Speaker Foam W1312-40016
To Next Page
