Keysight Technologies X Series Service Guide

Keysight N9010A EXA Service Guide 399
Replaceable Parts
Replaceable Parts
A1A3 Liquid Crystal Display
Serial number ≥ MY/SG51250000 2090-0997
Serial number < MY/SG51250000 2090-1040
A1A4 DC-DC Converter (LED display backlight power)
Serial number > MY51250000, SG51250000
0950-5235
Inverter Board (display backlight power)
Serial number < MY51250000, SG51250000
0950-4635
A1A5 Front Panel Daughter Board N9020-63193
A1MP1 Main Keypad E4410-40100
A1MP2 Display Keypad E4410-40101
A1MP3 Frequency Label, 3.6 GHz N9010-80008
A1MP4 Frequency Label, 7 GHz N9010-80009
A1MP5 Frequency Label, 13.6 GHz N9010-80010
A1MP6 Frequency Label, 26.5 GHz N9010-80011
A1MP7 LCD Glass Filter 1000-1513
A1MP8 LCD Lens Gasket W1312-40006
A1MP9 RPG Knob W1312-40017
A1MP10-13 Cable Clamp (Front Panel Cables) 1400-1439
A1MP14 Display Bracket
Serial number ≥ MY/SG51250000 W1312-00145
Serial number < MY/SG51250000 W1312-00023
A1MP15 Inverter Board Shield W1312-00024
A1MP16 Frequency Label, 32 GHz N9010-80006
A1MP17 Frequency Label, 44 GHz N9010-80007
A1MP23 Front Panel Interface/Speaker Bracket N9020-00028
A1MP24 Magnetic Shield (Display Bracket to Front Panel Interface/Speaker Bracket) N9020-00029
A1W1 Flex Circuit, Display to Front Panel Interface Board
Serial number ≥ MY/SG51250000 W1312-60122
Serial number < MY/SG51250000 W1312-60010
A1W2 Power Cable, Front Panel Interface Board to Inverter Board W1312-60011
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
