Keysight Technologies X Series Service Guide

400 Keysight N9010A EXA Service Guide
Replaceable Parts
Replaceable Parts
A1W3 Power Cable, Front Panel Interface board to DC-DC Converter W1312-60130
A1W4 Power Cable, DC-DC Converter to Display W1312-60131
A2 Analog I.F. Assembly
Standard Instruments, Option 503, 507, 513, 526 with Serial number
< MY/SG/US56480000
E4410-60104
Standard Instruments, Option 532, 544 with Serial number
< MY/SG/US56480000
N9020-60011
Standard Instruments with Serial number ≥ MY/SG/US56480000 N9020-60011
Option B40, MPB, or DP2 N9020-60011
A3 Digital I.F. Assembly
(Includes connector plate, EMI gasket, washers, nuts)
Standard Instruments N9020-60119
Options B40, MPB, or DP2 with Serial number < MY/SG/US56480000 N9020-60165
Options B40, MPB, or DP2 with Serial number ≥ MY/SG/US56480000 N9020-60016
A3W1 Cable Assembly, Smart Noise Source (Wire Harness) E4410-60163
A4
Refer also to
Service Note
N9010A-01A
CPU Replacement Kit (w/o disk drive)
Standard analyzers with Serial number ≥ MY/SG/US55340000
d
N9020-60248
Standard analyzers with Option 503, 507, 513, 526 and Serial number
≥ MY/SG/US52220000 and < MY/SG/US55230000
d
N9020-60140
Standard analyzers with Option 532, 544 and Serial number
≥ MY/SG/US51440000 and < MY/SG/US55230000
d
N9020-60140
Standard analyzers with Serial number < MY/SG/US50060000
N9020-60214
e
Option PC2 (Dual Core)
d
N9020-60081
Option PC4 (High Performance Dual Core)
d
N9020-60135
Option PC6 (Quad Core)
d
N9020-60247
A4A1 Disk Drive Interconnect Board W1312-63079
A4A2 Memory card, SD
Serial prefix number ≥ MY/SG/US5534 and any with Option PC6 or PC7
1819-1069
A4BT1 CPU Board Battery (CR2032) 1420-0356
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
