132 Keysight N9010A EXA Service Guide
Instrument Messages
Condition Errors 401 to 499, Power
Condition Errors 401 to 499, Power
Errors with signal power unleveled, overloaded, oscillating.
An event with the error number shown in the table means the condition has
been detected.
When the condition is cleared, an event with the error number plus 1000 is
generated.
For example, error 409 indicates a 50 MHz Oscillator Unleveled condition has
been detected, error 1409 indicates that failure has been cleared.
An E in the Error or Warning column means that an error is put up on the front
panel and sent out to SCPI when this condition is detected. A W in this column
means that a Warning is put up on the front panel but nothing goes out to
SCPI. Nothing in this column means nothing is put up; status bit only.
Err# Message Error or
Warning
Verbose/Correction Information
401 RPP Tripped W
403 Source Unleveled W
405 Source LO Unleveled E
407 LO Unleveled E
409 50 MHz Oscillator Unleveled E
411 50 MHz Input Power too High
for Cal
W
413 Input Overload W ADC Input overload
415 unused bit7 is set
417 LO Out Unleveled W
419 Preselector Overload
421 unused bit10 is set
423 unused bit11 is set
425 unused bit12 is set
427 unused bit13 is set
429 unused bit14 is set
