Keysight Technologies X Series Service Guide

Keysight N9010A EXA Service Guide 639
Functional Tests
Frequency Readout Accuracy
Frequency Readout Accuracy
Test Limits
Frequency Readout Accuracy is equivalent to the following equation:
See results table for actual values.
The frequency readout accuracy is measured in several spans and center
frequencies that allow both internal analyzer synthesizer modes and prefilter
bandwidths to be tested. Frequency reference error is eliminated by using the
same frequency standard for the analyzer and signal source.
0.25%span5%RBW2 Hz 0.5 horizontal resolution×++×+×()±
Item
Critical Specification
(for this test)
Recommended
Keysight Model
Adapter, Type-N (m), to
3.5 mm (f)
a
Frequency: 10 MHz to 1.51 GHz
VSWR: < 1.1:1
1250-1744
Adapter, 3.5 mm (f) to
3.5 mm (f)
a
Frequency: 10 MHz to 1.51 GHz
VSWR: < 1.1:1
83059B
Adapter, 2.4 mm (f) to
2.4 mm (f)
b
Frequency: 10 MHz to 1.51 GHz
VSWR: < 1.1:1
11900B
Cable, 2.4 mm,
1 meter
b
Frequency: 10 MHz to 1.51 GHz
VSWR: < 1.4:1
8120-6164
Cable, 3.5 mm,
1 meter
a
Frequency: 10 MHz to 1.51 GHz
VSWR: < 1.4:1
11500E
Cable, BNC, 120 cm Frequency: 10 MHz 10503A
Synthesized Sweeper Frequency: 10 MHz to 1.51 GHz PSG
a. For Options 503, 507, 513, and 526
b. For Options 532 and 544
