Keysight N9010A EXA Service Guide 401
Replaceable Parts
Replaceable Parts
A5
Refer also to
Service Note
N9010A-03
Disk Drive Replacement Kit
Serial number ≥ MY/SG/US50060000 (Solid State, SATA
d
)
or Option SSD with Win XP OS
N9020-60125
Serial number ≥ MY/SG/US54200000
Option PC4 with WES7 OS, or Option PC6
N9020 -60343
Serial number < MY/SG/US50060000 (IDE) N9020-60066
A5MP1 Disk Drive Tray W1312-40078
A5MP2 Disk Drive Rear Panel W1312-00103
A5MP3 Disk Drive Assembly Handle 1440-0421
A5W1 Disk Drive Ribbon Cable 8121-1611
A6 Power Supply 0950-5012
A7 Midplane Assembly N9020-60120
A8 Motherboard Assembly N9000-66404
A9 RF Attenuator A
0 to 4 dB (Options 503, 507, 513, 526) 33360-60008
0 to 10 dB (Options 532, 544) 33326-60013
A10 RF Attenuator B
0 to 66 dB (Options 503, 507, 513, 526) 33321-60083
0 to 60 dB (Options 532, 544) 33325-60020
A11 Low Band Switch Assembly
Option 503
E4410-60121
f
Options 507, 513, 526 E4410-60121
Options 532, 544 N9020-60051
A12 YTF Preselector (except Option 503)
Options 507, 513, 526 5087-7382
Options 532, 544 5087-7383
A12MP1 Gap Pad YTF Base 5022-7179
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
To Next Page
