Keysight Technologies X Series Service Guide

402 Keysight N9010A EXA Service Guide
Replaceable Parts
Replaceable Parts
A13 RF Front End Assembly
Options 503, 507, 513, 526 with Serial number < MY/SG/US56480000
N9020-60189
c
Options 503, 507, 513, 526 with Serial number ≥ MY/SG/US56480000
N9020-60314
c
Options 532, 544 with Serial number < MY/SG/US56480000
N9010-60007
c
Options 532, 544 with Serial number ≥ MY/SG/US56480000
N9010-60039
c
A13A1 Bandpass Filter
For A13 part number E4410-60154 0955-1719
For all other A13 part numbers 0955-2469
A13W1 Cable Assembly, A13J10 to A13A1 Input (Semi Rigid)
For A13 part number E4410-60154 E4410-20188
For all other A13 part numbers for Options 503, 507, 513, 526 E6607-21178
For all other A13 part numbers for Options 532, 544 N9020-20229
A13W2 Cable Assembly, A13J11 from A13A1 Output (Semi Rigid)
For A13 part number E4410-60154 E4410-20189
For all other A13 part numbers for Options 503, 507, 513, 526 N9020-20231
For all other A13 part numbers for Options 532, 544 N9020-20046
A13MP1 Spacer, Bandpass Filter Mounting Adapter
(All except A13 part number E4410-60154)
E6607-25005
A14 L.O. Synthesizer Assembly
Serial number ≥ MY/SG/US56480000 N9020-60118
Serial number < MY/SG/US56480000 E4410-60188
A15 Front End Control Assembly
Standard analyzers, Options 503, 507, 513, 526 with
Serial number < MY51250493, < SG51250069, < US51450000
c
N9020-60127
Standard analyzers, Options 503, 507, 513, 526 with
Serial number ≥ MY51250493, ≥ SG51250069, ≥ US51450000
N9020-60098
Options B40, MPB, DP2, CR3, CRP, 532, 544
g
N9020-60172
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
