Keysight Technologies X Series Service Guide

Keysight N9010A EXA Service Guide 403
Replaceable Parts
Replaceable Parts
A16 Reference Assembly
Serial number ≥ MY/SG/US56480000 N9020-60200
Serial number < MY/SG/US56480000 E4410-60108
AT1 Fixed Attenuator, 6 dB
(Option 507, 513, 526 with Options B40, MPB, or DP2)
(connects to SW2)
08493-60026
B1-B2 Fan 3160-4199
J1 Type-N (f) RF Input Connector Assembly (Option 503, 507, 513, 526) 5002-0702
2.4 m Input Connector Assembly (Option 532, 544) N9030-60011
EMI O-Ring 18.75 mm ID
(used between RF Input Connector and Front Frame)
8160-1637
J2 EXT MIXER Connector (discard washer and nut, if supplied) 1250-1666
MP1 Chassis Base
Serial number < MY/SG/US52180000 (Option 503, 507, 513, 526) E4410-00102
Serial number > MY/SG/US52180000 (Option 503, 507, 513, 526) N9020-00032
Serial number > MY/SG/US51440000 (Option 532, 544) N9020-00032
MP2 Chassis Side, Right (inner)
Serial number < MY/SG/US52180000 (Option 503, 507, 513, 526) W1312-00046
Serial number > MY/SG/US52180000 (Option 503, 507, 513, 526) W1312-00135
Serial number > MY/SG/US51440000 (Option 532, 544) W1312-00135
MP3 Chassis Side, Left (inner)
Serial number < MY/SG/US52180000 (Option 503, 507, 513, 526) W1312-00047
Serial number > MY/SG/US52180000 (Option 503, 507, 513, 526) W1312-00136
Serial number > MY/SG/US51440000 (Option 532, 544) W1312-00136
MP4 Midplane Bracket W1312-00048
MP5 Chassis Front Bracket
Serial number < MY/SG/US52180000 (Option 503, 507, 513, 526) W1312-00049
Serial number > MY/SG/US52180000 (Option 503, 507, 513, 526) W1312-00098
Serial number > MY/SG/US51440000 (Option 532, 544) W1312-00098
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
