Keysight Technologies X Series Service Guide

404 Keysight N9010A EXA Service Guide
Replaceable Parts
Replaceable Parts
MP6 Fan Bracket
Serial number < MY/SG/US52180000 (Option 503, 507, 513, 526) W1312-00133
Serial number > MY/SG/US52180000 (Option 503, 507, 513, 526) W1312-00137
Serial number > MY/SG/US51440000 (Option 532, 544) W1312-00137
MP7 Top Brace (includes foam strips) N9020-60018
MP8 Chassis Side, Right (Outer, attaches to Lowband Switch bracket, Attenuator
brackets, and Chassis bottom)
Serial number < MY/SG50510001
h
E4410-00101
Serial number ≥ MY/SG50510001 to < MY/SG/US52180000
(Option 503, 507, 513, 526)
N9020-00031
Serial number ≥ MY/SG52180000 (Option 503, 507, 513, 526) N9020-00034
Serial number ≥ MY/SG51440000 (Option 532, 544) N9020-00034
MP9 Rear Panel Replacement Kit (includes foam strip)
Serial number < MY/SG/US52180000 (Option 503, 507, 513, 526) N9020-60028
Serial number > MY/SG/US52180000 (Option 503, 507, 513, 526) N9020-60142
Serial number > MY/SG/US51440000 (Option 532, 544) N9020-60142
MP10 Label, AUX IF OUT (rear panel) N9020-80081
MP11-12 Coax Cable Clips 5041-7250
MP13-15 Tie Wrap (For long semi-rigid cables) 1400-0249
MP16 Dress Cover (includes magnetic gasket)
Serial number < MY/SG/US52180000 (Option 503, 507, 513, 526) N9020-60020
Serial number > MY/SG/US52180000 (Option 503, 507, 513, 526) N9020-60141
Serial number > MY/SG/US51440000 (Option 532, 544) N9020-60141
MP17-20 Rear Feet (Benchtop Configuration) 5041-9611
MP21-22 Strap Handles (Benchtop Configuration) N9020-60002
MP25-26 Fan Guard 3160-0281
MP27-34 Rivet, Fan Mounting (8 pieces) 0361-1272
MP35 Z-Bracket Power Supply to Chassis W1312-00016
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
