Keysight Technologies X Series Service Guide

Keysight N9010A EXA Service Guide 405
Replaceable Parts
Replaceable Parts
MP36-37 Attenuator Bracket
Option 503, 507, 513, 526 N9020-00052
Option 532, 544 N9020-00019
MP38 Low Band Switch Assembly Bracket
Serial number < MY/SG/US50510001, Option 503, 507, 513, 526 E4410-00109
Serial number ≥ MY/SG/US50510001, Option 503, 507, 513, 526 N9020-00023
Option 532, 544 N9020-00013
MP39 O-ring, Type N (f) RF Input Connector 8160-1637
MP40 PC Board Plastic Guides (10 pieces) W1312-40001
MP41-44 Front Bumpers (Option PRC, Portable) W1312-40020
MP45-48 Rear Bumpers (Option PRC, Portable) W1312-40021
MP49 Bail Handle (Option PRC, Portable) W1312-60036
MP50 Front Panel Protective Cover (Option CVR) W1312-40025
n/a Front End Troubleshooting Kit N9020-60005
n/a Front End Troubleshooting Bd. E4410-60115
MP51 CPU & Power Supply Guide Pin Grommets (8 pieces) 0400-0353
MP52 50 Ω Termination (for A13) 1810-0118
MP53 Spiral Wrap 0890-0025
MP54 Rear Frame Lock Washer (External Reference Cable) 2190-0102
MP55 Rear Frame Lock Nut (External Reference Cable) 0590-2332
MP57-60 Bottom Feet Hole Plugs (Option PRC, Portable) W1312-40032
MP61-64 Strap Handle Plugs (Option PRC, Portable) W1312-40024
MP65 Top Bracket, Reference Assembly N9000-00104
MP66-69 Bottom Feet (Benchtop Configuration) 5041-9167
MP70-71 Tilt Stands (Benchtop Configuration) 1460-1345
MP72-75 Bottom Feet Key Locks (Benchtop Configuration) 5021-2840
MP78 Input Connector O-Ring 8160-1637
MP79 Bracket, Preselector Bypass Switch 1
(on top of bottom switch)
E4410-00104
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
