Keysight Technologies X Series Service Guide

406 Keysight N9010A EXA Service Guide
Replaceable Parts
Replaceable Parts
MP80 Bracket, Preselector Bypass Switch 2
(on top of top switch)
E4410-00110
MP81 Shield, Magnetic, Attenuator A (Option 532, 544) N9020-00043
MP82 Shield, Magnetic, Attenuator B (Option 532, 544) N9020-00044
MP83 Gusset, Chassis (near RF Input connector) W1312-00093
SW1 & 2 Coaxial Switch
(Options B40, MPB, or DP2)
N1810-60069
SW4 Transfer Switch, 50 GHz
(Options B40, MPB, or DP2)
87222-60031
W1 Cable, Front Panel Interface Board to Motherboard (Ribbon)
Serial number ≥ MY/SG48010101, US48010001
i
N9020-60036
Serial number < MY/SG48010101, US48010001
j
E4410-60171
W2 Cable, Interconnect from A2J820 to A3J20
Standard Instruments, Option 503, 507, 513, 526 with Serial number
< MY/SG/US56480000
E4410-60162
Standard Instruments, Option 503, 507, 513, 526 with Serial number
≥ MY/SG/US56480000
N9020-60046
Option 532, 544 N9020-60046
Option B40, MPB, or DP2 N9020-60046
W3 Cable Assembly, A11J2 to A13J2 (Semi Rigid)
Serial number < MY/SG50510001, Option 503, 507, 513, 526 E4410-20162
Serial number ≥ MY/SG50510001, Option 503, 507, 513, 526 N9020-20101
Option 532, 544 N9020-20131
W4 Cable Assembly, A14J740 to A13J4 (Semi Rigid) N9020-20156
W5 Cable Assembly, A16J702 to A13J1 (Semi Rigid)
Serial number < MY/SG/US56480000 N9020-20155
Serial number ≥ MY/SG/US56480000 N9020-20064
W6 Cable Assembly, A16J703 to A14J200 (Semi Rigid)
Serial number < MY/SG/US56480000 N9020-20154
Serial number ≥ MY/SG/US56480000 N9020-20033
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
