Keysight Technologies X Series Service Guide

Keysight N9010A EXA Service Guide 407
Replaceable Parts
Replaceable Parts
W7 Cable Assembly, A12 Output to A13J9 (Semi Rigid)
Option 503, 507, 513, 526 N9020-20124
Option 532, 544 N9010-20006
W8 Cable Assembly, A11J3 to A12 Input (Semi Rigid)
Serial number < MY/SG50510001, Option 503, 507, 513, 526 E4410-20160
Serial number ≥ MY/SG50510001, Option 503, 507, 513, 526 N9020-20123
Option 532, 544 N9010-20005
W9 Cable Assembly, A10 Output to A11J1 (Semi Rigid)
Serial number < MY/SG50510001, Option 503, 507, 513, 526 E4410-20159
Serial number ≥ MY/SG50510001, Option 503, 507, 513, 526 N9020-20153
Option 532, 544 N9010-20004
W10 Cable Assembly, J1 to A9 Input (Semi Rigid)
Serial number < MY/SG50510001, Option 503, 507, 513, 526 E4410-20156
Serial number ≥ MY/SG50510001, Option 503, 507, 513, 526 N9020-20141
Option 532, 544 N9020-20133
W11 Cable Assembly, A9 Output to A10 Input (Semi Rigid)
Option 503, 507, 513, 526 N9020-20142
Option 532, 544 N9010-20002
W12 Cable Assembly, A16J710 to A3J14 (Flexible Coax) 8121-1401
W13 Cable Assembly, A2J601 to A3J15 (Flexible Coax) 8121-1411
W14 Cable Assembly, A16J711 to A2J300 (Flexible Coax) 8121-1401
W15 Cable Assembly, A13J7 to A2J100 (Flexible Coax) 8121-1400
W16 Cable Assembly, A9 & A10 to A15J801 or A15J102 (Ribbon Cable) E4410-60157
W17 Cable Assembly, A13 to A15J104 (Ribbon Cable) E4410-60156
W18 Cable Assembly, A11J4 to A15J103 or A15J700 (Ribbon Cable)
Option 503, 507, 513, 526 E4410-60160
Option 532, 544 N9020-60092
W19 Cable Assembly, A16J701 to A9 Cal Signal Input/Port 2 (Semi Rigid)
Option 503, 507, 513, 526 with Serial number < MY/SG/US56480000 E4410-60169
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
