Keysight Technologies X Series Service Guide

408 Keysight N9010A EXA Service Guide
Replaceable Parts
Replaceable Parts
Option 532, 544 with Serial number < MY/SG/US56480000 N9010-20003
Option 503, 507, 513, 526 with Serial number ≥ MY/SG/US56480000 E4410-60160
Option 532, 544 with Serial number ≥ MY/SG/US56480000 N9020-60092
W20 Cable Assembly, A13J6 to A16J705 (Flexible Coax) 8121-1400
W22 Cable Assembly, A15J301 or A15J300 to A12J1 (Wire Harness)
Standard Instruments, Option 507, 513, 526 with Serial number
< MY51250493, < SG51250069, < US51450000
E4410-60158
Standard Instruments, Option 507, 513, 526 with Serial number
> MY51250493, > SG51250069, > US51450000
N9020-60059
Options B40, MPB, DP2, CR3, CRP, 532, 544 N9020-60059
W23 Cable Assembly, Ext. Reference Cable (rear frame) to A16J704 (Flexible Coax) 8121-1402
W26 Cable Assembly, A13J13 to A15J903 (Flexible Coax) Option EXM 8121-2025
W27 Cable Assembly, J2 (front panel) to W28 (Semi Rigid) Option EXM N9020-20166
W28 Cable Assembly, W27 to A13J8 (Semi Rigid) Option EXM N9020-20198
W30 Cable Assembly, A15J801 to SW1 and SW2 or SW4 (Wire Harness) E4410-60159
W31 Cable Assembly, SW2 Center Port to A11J3 (Semi-rigid) E4410-20161
W32 Cable Assembly, SW2 Port 2 to A12J2 (Semi-rigid) E4410-20163
W33 Cable Assembly, SW1 Port 2 to A12J1 (Semi-rigid) E4410-20165
W34 Cable Assembly, SW1 Center Port to A13J9 (Semi-rigid) E4410-20164
W35 Cable Assembly, AT1 to SW1 Port 1 (Semi-rigid) E4410-20178
W36 Cable Assembly, A15J902 to A13J7 (Flexible Coax) 8121-1862
W37 Cable Assembly, A15J900 to A2J100 (Flexible Coax) 8121-1401
W38 Cable Assembly, A15J901 to A3J15 (Flexible Coax) 8121-1861
W39 Cable Assembly, A15J1100 to Rear Panel Port 9 (Flexible Coax) 8121-2028
W40 Cable Assembly,A13J6 to A3J17 (Flexible Coax) 8121-1940
W41 Cable Assembly, A2J601 to A3J19 (Flexible Coax) 8120-8868
W42 Cable Assembly, A16J706 to A3J14 (Flexible Coax) 8121-1401
W43 Cable Assembly, A16J705 to A3J18 (Flexible Coax) 8121-1401
W45 Cable Assembly, A11J3 to SW4 Port 1 (Semi Rigid)
Option 532, 544 with Option MPB
N9010-20009
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
