Keysight N9010A EXA Service Guide 409
Replaceable Parts
Replaceable Parts
W46 Cable Assembly, SW4 Port 2 to A13J9 (Semi Rigid)
Option 532, 544 with Option MPB
N9020-20130
W47 Cable Assembly, SW4 Port 3 to A12 Output (Semi Rigid)
Option 532, 544 with Option MPB
N9020-20129
W48 Cable Assembly, SW4 Port 4 to A12 Input (Semi Rigid)
Option 532, 544 with Option MPB
N9020-20128
W49 Reserved
W50 Cable Assembly, A16J726 to A3J17 (Flexible Coax) 8121-1401
W54 Cable Assembly, A16J716 to A3J14 (Flexible Coax) 8121-2288
a. Frequency range label not included in kit. See A1MP3 - A1MP6 and A1MP16 - A1MP17
b. Non-orderable item, see A1A1
c. Replacement Kit
d. Disk drive removable through rear panel.
e. This kit includes upgrade to newer CPU and WES7 Operating System. It does NOT include minor enhancement
updates.
f. Later analyzers with Option 503 ship with A11 p/n N9020-65255, however the preferred service replacement is
E4410-60121.
g. Later analyzers with any combination of Options B40, MPB, DP2, CR3, 532, or 544 but without Option CRP ship
with A15 p/n N9020-65222, however the preferred service replacement is N9020-60172.
h. Refer to part number for S/N > MY/SG 50510001 if the analyzer is equipped with Option B40, MPB, or DP2.
i. Locking connector on both ends
j. Locking connector, Motherboard only
Table 14-1 All Replaceable Parts
Reference
Designator
Description Part Number
