Keysight Technologies X Series Service Guide

410 Chapter 14 Replaceable Parts Replaceable Parts
Table 14-2 Attaching Hardware
Attach To Qty Part Number Type Tool Torque
Analog IF Digital IF 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Analog IF (Top Shield) Analog IF (Bottom Shield) 16 0515-0664 M3 X 0.5
(12 mm long)
Torx T-10 9 inch-lbs
Attenuators Attenuator Bracket 2 per 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Attenuators Chassis 2 per 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Bail Handle Front Frame 4 0515-0435 M4 X 0.7
(14 mm long)
Torx T-20 21 inch-lbs
Bandpass Filter Bandpass Filter Spacer 3 0515-0661 M2 X 0.4
(6 mm long)
Torx T-6 3 inch-lbs
Bandpass Filter Spacer RF Front End Assembly 4 0515-0658 M2 X 0.4
(6 mm long)
Torx T-6 3 inch-lbs
Bracket, Preselector Bypass
SW1
Low Band Switch Bracket 2 0515-1992 M2.5 X 0.45
(20 mm long)
Torx T-8 6 inch-lbs
Bracket, Preselector Bypass
SW2
Low Band Switch Bracket 2 0515-1992 M2.5 X 0.45
(20 mm long)
Torx T-8 6 inch-lbs
Chassis Bottom Chassis Sides, Midplane
& Front Bracket
15 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Chassis Side
(Right Outside)
Lowband Switch Bracket,
Attenuator Brackets, Chassis
bottom
7 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
CPU Assembly Chassis 6 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
