Keysight Technologies X Series Service Guide

Chapter 14 411
Replaceable Parts
Replaceable Parts
CPU Shield CPU & Hard Disk Drive 19 0515-1227 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
CPU Shield
(Option PC2)
CPU Assembly 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
19 0515-1227 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
DC-DC Converter Display Bracket
Serial number
> MY/SG51240000
2 0515-0430 M3 X 6.0 Torx T-10 9 inch-lbs
Digital IF LVDS Connector 2 0515-4439 M2.5 X 6.0 Small Pozi 5 inch-lbs
Display Display Bracket
Serial number
> MY/SG51240000
4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Display Display Bracket
Serial number
> MY/SG51240000
4 0515-1934 M2.5 X 0.45
(6 mm long)
Torx T-8 5 inch-lbs
Display Bracket & Front Panel
Interface/Speaker Bracket
Front Frame 7 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Disk Drive
(Option PC2, PC3, PC4, PC5)
Disk Drive Tray 4 0515-0372 (<Rev 6)
0515-1035 (>Rev 7)
(flat-head screw)
M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Disk Drive Interconnect
(Option PC2, PC3, PC4, PC5)
CPU Assembly 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Disk Drive Handle
(Option PC2, PC3, PC4, PC5)
Disk Drive Rear Panel 2 0515-1227 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Table 14-2 Attaching Hardware
Attach To Qty Part Number Type Tool Torque
