Keysight Technologies X Series Service Guide

412 Chapter 14 Replaceable Parts Replaceable Parts
Disk Drive Rear Panel
(Option PC2, PC3, PC4, PC5)
Disk Drive Tray 4 0515-2219 M2.5 X 0.45
(5 mm long)
Torx T-8 9 inch-lbs
External Reference BNC Rear Panel 1 2190-0102 Lock Washer n/a n/a
External Reference BNC Rear Panel 1 0590-2332 Hex Nut 9/16” Nut
Driver
21 inch-lbs
Fan Assembly Chassis 5 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Fan Fan Bracket 8 0361-1272 Rivets n/a n/a
Front Bumpers
(Opt. PRC)
Front Frame 8 0515-0435 M4 X 0.7
(14 mm long)
Torx T-20 21 inch-lbs
Front Chassis Bracket &
Midplane Bracket
Chassis Sides 10 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Frame Chassis 8 0515-2032 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Frame Bottom Chassis 2 per 0515-2032 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Panel Assy. Chassis 6 0515-2032 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Panel Daughter Board Front Frame 3 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Front Panel Interface Front Frame 13 0515-1521 M3 X 0.5
(5 mm long)
Torx T-10 9 inch lbs.
Inverter Board Inverter Bracket 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Table 14-2 Attaching Hardware
Attach To Qty Part Number Type Tool Torque
