Keysight Technologies X Series Service Guide

Chapter 14 413
Replaceable Parts
Replaceable Parts
Low Band Switch Assy. Chassis 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Low Band Switch Assy. Low Band Switch Bracket 4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Low Band Switch Bracket. Bracket, Preselector Bypass
SW2
1 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Midplane Assembly Midplane Bracket 6 0515-0375 M3 X 0.5
(16 mm long)
Torx T-10 9 inch-lbs
Motherboard Chassis Base 4 0515-0372 M3 X0.5
(8 mm long)
Torx T-10 9 inch-lbs
Power Supply 'Z' Bracket Chassis Sides 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Power Supply 'Z' Bracket Power Supply 3 0515-1227 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Rear Bumper Feet (Opt. PRC) Rear Panel 4 0515-1619 M4 X 0.7
(25 mm long)
Torx T-20 21
inch-lbs.
Rear Bumper Feet (Opt. PRC) Rear Panel 4 3050-0893 Flat Washer n/a n/a
Rear Feet Rear Panel 4 0515-1619 M4 X 0.7
(25 mm long)
Torx T-20 21 inch-lbs
Rear Feet Rear Panel 4 3050-0893 Flat Washer n/a n/a
Rear Frame Chassis 18 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Rear Frame Top Bracket, Reference
Assembly
4 0515-1946 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Table 14-2 Attaching Hardware
Attach To Qty Part Number Type Tool Torque
