Keysight Technologies X Series Service Guide

414 Chapter 14 Replaceable Parts Replaceable Parts
RF Front End Assembly Chassis 4 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
RF Input Connector Chassis 2 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Strap Handle Plugs
(Opt. PRC)
Instrument Cover 4 0515-5209 M5 X 0.8
(14 mm long)
Torx T-20 21 inch-lbs
Strap Handles Chassis Side 2 per 0515-0710 M4 X 0.8
(18 mm long)
Torx T-20 21 inch-lbs
SW1 Bracket SW1 2 0515-1992 M2.5 X 0.45
(20 mm long)
Torx T-8 6 inch-lbs
SW2 Bracket SW2 2 0515-1992 M2.5 X 0.45
(20 mm long)
Torx T-8 6 inch-lbs
SW2 Bracket Low Band Switch Bracket 1 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Top Brace Top Bracket, Reference
Assembly
4 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Top Brace Board Assemblies 6 0515-1946 M3 X 0.5
(6 mm long)
Torx T-10 9 inch-lbs
Top Brace & Reference
Assembly Bracket
Chassis Components 12 0515-0372 M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
YTF Preselector Chassis 4 0515-0372
(except Option 503)
M3 X 0.5
(8 mm long)
Torx T-10 9 inch-lbs
Table 14-2 Attaching Hardware
Attach To Qty Part Number Type Tool Torque
