126 Keysight N9010A EXA Service Guide
Instrument Messages
Condition Errors 201 to 299, Signal Integrity
211 Carrier(s) incorrect
or missing
E
213 Freq Out of Range E
213 Freq Out of Range;
External LO
E One or more external LO frequencies are out of range.
Check that the LO frequency limits are set correctly and
check the entered measurement frequencies and
measurement mode.
213 Freq Out of Range;
System input (IF)
E One or more system input frequencies are out of range. If
using a frequency list, check that all entries are valid for
current measurement mode.
215 Sync Error E W-CDMA: Cannot sync DPCCH pilot.
Cannot synchronize measurement with DPCCH pilot for
Power Control measurement, because the pilot signal
cannot be found. Make sure DPCCH is present in the
W-CDMA uplink signal, and that the slot format and
scramble code are set correctly.
215 Sync Error;Midamble
sync fail
E Failed to find the uplink slot, which caused the
synchronization with the midamble to fail.
215 Sync Error;No freq ref
pilot burst
E The pilot burst used for frequency reference is not active.
215 Sync Error;No pilot
burst
E There is no Pilot burst detected.
215 Sync Error;Preamble
length zero
E Burst type is "Data" or "Preamble" and the measurement
cannot find a Preamble
215 Sync Error;Sync code
not found
E Synchronization code is not found in the measured time
slot.
