Keysight Technologies X Series Service Guide

Keysight N9010A EXA Service Guide 31
Overview
Service Equipment You Will Need
High Sensitivity
Millimeter Power Sensor
(for Options > 532)
Frequency Range: 50 MHz to 50 GHz
Amplitude Range: −70 to −20 dBm
Zero Set: ± 20 pW
Zero Drift: < ± 4 pW
Measurement Noise: < 4 pW
Cal Factor Uncertainty: < 4.5%
VSWR: 50 MHz to 100 MHz: 1.19:1
100 MHz to 4 GHz: 1.15:1
4 GHz to 12.4 GHz: 1.20:1
12.4 GHz to 18 GHz: 1.29:1
18 GHz to 34 GHz: 1.37:1
34 GHz to 40 GHz: 1.61:1
40 GHz to 50 GHz: 1.89:1
Input Connector: 2.4 mm (m)
8487D A, P
Low Power Microwave
Power Sensor
(2 required)
(for Option P07 only)
Frequency Range: 50 MHz to 26.5 GHz
Amplitude Range: −70 to +20 dBm
Zero Set: ± 50 pW
Zero Drift: < ± 4 pW
Measurement Noise: < 4 pW
Cal Factor Uncertainty: < 3.0%
VSWR: 50 MHz to 100 MHz: 1.15:1
100 MHz to 2 GHz: 1.10:1
2 GHz to 12.4 GHz: 1.15:1
12.4 GHz to 18 GHz: 1.20:1
18 GHz to 26.5 GHz: 1.25:1
Input Connector: 3.5 mm (m)
8485D
e
A, P
Power Sensor Cable
(2 required)
11730A A, P, T
Standards
Frequency Standard Frequency: 10 MHz
Accuracy: < ±1 e10
−10
Symmetricom
5071A
Keysight 5061B,
5071A
A, P
50 MHz,
−25 dBm Calibrator
Frequency Drift: < 2.5 kHz
Typical VSWR: 1.06:1
Output Power Variation: ±.004 dB
Total Harmonic Content: −45 dBc
Z5602A
Opt H51
A
Attenuators
10 dB
Step Attenuator
Range: 0 to 80 dB
Accuracy:
Characterized by standards lab
f
Calibrated at 50 MHz
VSWR: at 50 MHz: ≤ 1.05:1
8496G
(Option 001,
H50)
8496H
(Option 001, H50)
P
Table 1-1 Required Test Equipment
Instrument Critical Specifications Recommended
Model
a
Alternative
Model
Use
b
