Keysight Technologies X Series Service Guide

Keysight N9010A EXA Service Guide 35
Overview
Service Equipment You Will Need
Filters
300 MHz Low Pass
(2 Required)
Cutoff Frequency: 300 MHz
Rejection at > 435 MHz: > 45 dB
VSWR: ≤ 1.5:1
BNC (m, f)
Telonic
Berkeley
TLP 300-4AB4
0955-0455 P
1.8 GHz Low Pass
(2 Required)
Cutoff frequency: 1.8 GHz
Rejection at 2.1 GHz to 6 GHz: > 45 dB
Insertion Loss @ 1.8 GHz: < 1 dB
VSWR: ≤ 1.50:1 DC to 1.8 GHz
Connector: SMA (f) to SMA (f)
RLC L-1636 0955-0491 P
4.4 GHz Low Pass
(2 Required)
Cutoff frequency: 4.4 GHz
Rejection at > 5.5 GHz: > 42 dB
Insertion Loss @ 1.8 GHz: < 1 dB
VSWR: ≤ 1.50:1 DC to 1.8 GHz
Connector: SMA (f) to SMA (f)
K + L
ML253-4499/X
U-N/NP
9135-0005
360D
P
5.0 GHz Low Pass 3 dB frequency: 5.25 GHz
60 dB Rejection: > 6.7 GHz
VSWR: 1.35:1
RLC
F-30-5000-RF
P
8.0 GHz Low Pass 3 dB frequency: 8.4 GHz
60 dB Rejection: > 10.8 GHz
VSWR: 1.35:1
RLC
F-30-8000-RF
P
12.4 GHz Low Pass 3 dB frequency: 13.0 GHz
60 dB Rejection: > 16.74 GHz
VSWR: 1.35:1
RLC
F-30-12.4-RF
P
Adapters
Type-N (f) to Type-N (f) Frequency: DC to 18 GHz
VSWR: ≤ 1.13:1
1250-1472 P
Type-N (m) to Type-N
(m)
Frequency: DC to 18 GHz
VSWR: ≤ 1.13:1
1250-1475 P
Type-N (f) to BNC (m) Frequency: DC to 1.3 GHz
VSWR: ≤ 1.13:1
1250-1477 P, T
Type-N (m) to BNC (m) Frequency: DC to 1.3 GHz
VSWR: ≤ 1.13:1
1250-1473 P, T
Type-N (m) to BNC (f) Frequency: DC to 1.3 GHz
VSWR: ≤ 1.13:1
1250-1476 P
Type-N (m) to
3.5 mm (m)
Frequency: DC to 18 GHz
VSWR: ≤ 1.08:1
1250-1743 P
Table 1-1 Required Test Equipment
Instrument Critical Specifications Recommended
Model
a
Alternative
Model
Use
b
