354 Keysight N9010A EXA Service Guide
Power Supply/Midplane Troubleshooting
A7 Midplane Description
Figure 10-3 Midplane
Item Description
1 A2 Analog I.F. Assembly
A3 Digital I.F. Assembly
2 A4 CPU Replacement Kit (w/o disk drive)
3 A6 Power Supply
4 A16 Reference Assembly
5 A14 L.O. Synthesizer Assembly
6 A15 Front End Control Assembly
7 A7 Midplane Assembly
The L.O. Synthesizer, Front End Control Assembly, Analog IF, and Digital IF plug into the
Motherboard. All other assemblies mentioned plug into the Midplane from the rear of the
instrument.
