Keysight Technologies X Series Service Guide

Keysight N9010A EXA Service Guide 597
Post-Repair Procedures
Post-Repair Procedures
A16
Reference
Assembly
FPGA Synchronization
c
10 MHz Frequency Reference Adjust
50 MHz Calibrator Amplitude Adjust
4800 MHz Calibrator Amplitude Adjustment
(Option MPB)
Frequency Reference Accuracy
Residual Responses
Displayed Average Noise Level
Frequency Readout Accuracy
Count Accuracy
Absolute Amplitude Accuracy
Phase Noise (All Tests)
SW1, SW2, or
SW4
Preselector
Bypass
Switch (Opt MPB)
Frequency Response (all tests)
Attenuator Slope
Hardware Statistical Reset
Frequency Response (all)
a. Calibration Application Software is required for all performance tests and most adjustments. For
details go to http://www.keysight.com/find/calibrationsoftware
b. IF Frequency Response adjustment only performed if Option B25 and/or B40 are present and ana-
lyzer is equipped with Option MPB.
c. See the Additional Tasks section in this chapter for detailed instructions on this task.
d. To set the instrument time and date press Start, Control Panel, Date Time Language and
Regional Options, Date and Time
e. Before replacing the A5 Disk Drive, see the “Calibration Data Backup and Restore” section in this
chapter for details.
f. See Chapter 17, “Instrument Software” for instructions on updating the instrument software to the
latest version.
Some Adjustment tests may be found in the Utility portion of the Test Plan.
Table 16-1 Post-Repair Testing Requirements (Continued)
Assembly
Adjustments to Perform
(in the order listed)
a
Performance Verifications to Perform After
Adjustments
a
