1. Tachometer
2. Speedometer
3. Engine coolant temperature gauge
4. Fuel gauge
5. Warning and indicator lights
6. LCD display
❈ The actual cluster in the vehicle
may differ from the illustration.
For more information, refer to
Gauges on page 4-62.
Instrument cluster control
Adjusting instrument cluster
illumination (if equipped)
