Kia Optima 2017 - Gauges; Speedometer; Tachometer

[Type A]
1. : MODE button for changing
modes
2. / /OK: SELECT scroll switch for
setting the selected item and RE‐
SET scroll switch for resetting
items
[Type B]
1.
: MODE button for changing
modes
2. / /OK: SELECT scroll switch for
setting the selected item and RE‐
SET scroll switch for resetting
items
3. : RETURN button for move the
previous mode or item (if equipped)
❈ For the LCD modes, refer to 󳱷LCD
display󳱸 on page 4-68.
Gauges
Speedometer
Type A (km/h)
OJF045102
Type B (MPH,
km/h)
OJF045102L
The speedometer indicates the speed
of the vehicle and is calibrated in miles
per hour (mph) and/or kilometers per
hour (km/h).
Tachometer
DieselGasoline
OJF045106-OJF045103
The tachometer indicates the approxi‐
mate number of engine revolutions per
minute (rpm).
Use the tachometer to select the cor‐
rect shift points and to prevent lugging
and/or over-revving the engine.
CAUTION
Do not operate the engine within the
tachometer's RED ZONE. This may
cause severe engine damage.
Features of your vehicle
4-62
