Headlamp (High beam) bulb
replacement
OJF075076
1. Open the hood.
2. Remove the headlamp bulb cover
by turning it counterclockwise.
3. Disconnect the headlamp bulb
socket-connector.
4. Remove the bulb-socket from the
headlamp assembly by turning the
bulb-socket counterclockwise until
the tabs on the bulb-socket align
with the slots on the headlamp as‐
sembly.
5. Install a new bulb-socket assembly
in the headlamp assembly by align‐
ing the tabs on the bulb-socket
with the slots in the headlamp as‐
sembly. Push the bulb-socket into
the headlamp assembly and turn
the bulb-socket clockwise.
6. Install the headlamp bulb cover by
turning it clockwise.
Headlamp (High/Low beam) LED
replacement
OJFHP076192L
If the light bulb (Low (2), High (3)) does
not operate, we recommend that you
check with an authorized Kia dealer.
Smart cornering lamp bulb
replacement
OJF075077
1. Open the hood.
2. Remove the headlamp bulb cover
by turning it counterclockwise.
3. Remove the bulb-socket from the
headlamp assembly by turning the
bulb-socket counterclockwise until
the tabs on the bulb-socket align
with the slots on the headlamp as‐
sembly.
4. Remove the bulb from bulb-socket
by pulling it out.
5. Insert a new bulb by inserting it in‐
to the bulb-socket.
