(Continued)
• Never allow anyone to ride in the
luggage compartment. It is de‐
signed for luggage only.
• Maintain the balance of the vehicle
and locate the weight as far for‐
ward as possible.
CAUTION
Since the cargo security screen may
be damaged or malformed, do not
put the luggage on it when it is used.
Luggage rail system (wagon)
The luggage rail system may prevent
the luggage from sliding around in the
luggage compartment.
Built-in segmentation bar
• Put both pillars (A) from the segmen‐
tation bar in the openings from the
rail.
• To move the segmentation bar, put
your hand on the side of the pillar
and push down the lever arm (B).
• Make sure the pillars click into place.
• To release the belt, turn the upper el‐
ement (C) to the left or right until it
clicks.
• Now you can pull the belt (D) and se‐
cure your luggage by putting the belt
around the luggage and put the hook
(E) into the middle of the segmenta‐
tion bar (F).
• For bulky luggage, you can hook both
hooks into each other.
• To make sure the belt locks, put the
upper element (C) back into the lock
position (1).
CAUTION
• The segmentation bar must be
mounted and demounted with
both pillars simultaneously.
• Max. load:
30 kg with one belt
40 kg with two belts
4-187
4
Features of your vehicle
