❈ The actual engine room in the vehicle may differ from the illustration.
OJF075074L/OJF075140L
Gasoline Engine (Nu 2.0L - CVVL)
Gasoline Engine (Nu 2.0L - MPI)
1. Engine coolant reservoir.......................................... p. 8-49
2. Engine oil filler cap.......................... .......................... p. 8-48
3. Brake/clutch fluid reservoir (if equipped).............. p. 8-52
4. Air cleaner................................. ................................. p. 8-56
5. Fuse box...................................................................... p. 8-76
6. Negative battery terminal................... ................... p. 8-62
7. Positive battery terminal.................... .................... p. 8-62
8. Engine oil dipstick...................................................... p. 8-46
9. Radiator cap............................... ............................... p. 8-50
10. Windshield washer fluid reservoir.......................... p. 8-53
2-07
2
Your vehicle at a glance
