If the stop (1) and tail (2) lamp (LED)
does not operate, we recommend that
you check with an authorized Kia deal‐
er.
Back-up lamp bulb replacement
(Wagon)
3. Remove the socket from the as‐
sembly by turning the socket coun‐
terclockwise until the tabs on the
socket align with the slots on the
assembly.
4. Remove the bulb from bulb-socket
by pulling it out.
5. Insert a new bulb by inserting it in‐
to the bulb-socket.
6. Install the socket in the assembly
by aligning the tabs on the socket
with the slots in the assembly.
Push the socket into the assembly
and turn the socket clockwise.
7. Install the service cover by putting
it into the service hole.
Maintenance
8-120
