7. ENGINE REMOVAL/INSTALLATION
7-7
MXU 500
Tap the rear propeller shaft with rubber
hammer and remove the rear propeller shaft
from the engine assembly.
Lower the cylinder head and rise the engine
rear side, then move the engine from the
frame left side.
Rear Propeller Shaf
t
Take care not to lose the compression
spring in the rear drive gear case end.
＊
