7. ENGINE REMOVAL/INSTALLATION
7-8
MXU 500
ENGINE INSTALLATION
Install the engine assembly into the frame.
Apply lightweight lithium-soap base grease
to the rear propeller shaft splines.
Install the rear propeller shaft into the
engine assembly.
Apply grease
Rear Propeller Shaf
t
Rear Propeller Shaf
t
Apply grease Apply grease
Apply lightweight lithium-soap base
grease to the rear output shaft splines.
＊
