13. DRIVE TRAIN
13-9
MXU 500
Apply molybdenum disulfide grease to the
entire surface of the cage and the inside of
the case side joint/wheel side joint.
Insert the cage into the case side joint and
fit a circlip in the groove of the case side
joint.
Circlip
Position
Grease
Case side joint Wheel side joint
Quantity 85 g (2.8 oz) 45 g (1.5 oz)
The tube of joint molybdenum disulfide
grease is included in the wheel side boot
set or wheel side joint assembly of spare
parts.
＊
Locate the opening of the circlip so that
the opening is not lined up with a ball.
＊
