Lexmark C925 - Page 167

To Next Page

To Previous Page

Repair information 4-23

5041-030

Go Back

4. Gently pull the lower op panel cover back, and lift the op panel guide up.

5. Remove the screw (C) securing the ground wire to the printer frame.
