2-24 Service Manual
5041-030
MPF service check
FRU Action
1 MPF tray paper guides Check the guides to ensure they are not binding. Also, check the
guides to ensure they are correctly adjusted for the paper in the
tray.
2
MPF roll cover Make sure the MPF roll cover is properly installed, and not
obstructing the paperpath. Check for broken tabs, and replace the
cover if any tabs are missing.
3
MPF roll
MPF pad
Check for wear or damage to feed rollers and pad.
Check for dirt on the roll and pad. Clean them with a lint free damp
cloth.
4
MPF clutch Check the MPF clutch cable for proper connection to the clutch
and CN 28 on the engine board.
5
MPF paper empty lever
(actuator)
MPF sensor
Make sure the MPF paper empty lever moves smoothly, and
doesn’t bind. Replace the lever if it is broken.
Check the MPF sensor cable for proper connection to the sensor
and CN14 on the engine board. Also check the cable for continuity.
6
Engine board If replacing the MPF clutch and sensor don’t resolve and MPF feed
issues, replace the engine board.
