1-4 Service Manual
5041-030
Printer specifications
This section varies by product type. It will be different in scanners, laser printers, and inkjet printers.
Power specifications
Average nominal power requirements for the base printer configuration. (Power levels are shown in watts.)
Electrical specifications
Low-voltage models
• 100 to 127 V ac at 50 to 60 hertz (Hz) nominal
• 90 to 137 V ac, extreme
High-voltage models
• 220 to 240 V ac at 50 to 60 hertz (Hz) nominal (not available in all countries and regions)
Clearances
Printing states Power
Off 0W
Sleep Mode 11W
Hibernate Mode 3W
Ready Mode 105W
Continuous printing 620W
1 Right 385 mm (15.16 in.)
2 Front 380 mm (15 in.)
3 Left 100 mm (3.94 in.)
4 Rear 100 mm (3.94 in.)
5 Top 100 mm (1.34 in.)
Allow additional clearance around the printer for
adding options.
